WAVE AIR 3 POCKET SET STEREO WIRELESS IEM IN EAR MONITOR SISTEM

Deskripsi

- UHF Stereo Wireless IEM portable

- Type C rechargeable battery

- high quality PREAMP and large Headroom for best Monitoring audio live experience

- Deattachable Antenna

- Metal Body

PRODUCT FEATURES

. UHF signal transmission, strong signal penetration, good anti-interference

and qood signal range

.No sense of delay, users can hardly perceive the delay of signal and sound,

suitable for real-time use

.Built-in rechargeable lithium battery, good battery life, convenient to use

anytime and anywhere

•Small size and light weight, metal shell and detachable antenna, excellent

workmanship

• The receiver can switch between stereo/mono modes, suitable for monitoring

in various ways

.Strong scalability, the transmitter can input music or microphone

dynamic/condenser lavalier microphone

SYSTEM TECHNICAL PARAMETERS

RF carrier frequency range: 560~590MHz

Total number of channels: 20

Frequency stability: 0.005%;

Effective working distance (optimal environment): > 80 meters;

Audio compression and expansion: DSP digital audio

Audio sampling depth: 24bit, 48K

Audio frequency response: 60Hz~20KHz;

Dynamic range:95 dB;

Audio signal-to-noise ratio: 120dB;

Total harmonic distortion:

Operating temperature range: -10°C~ +50°C:

RECEIVER TECHNICAL PARAMETERS

Receiver bandwidth: 560~590MHz(the actual version shall prevail)

Receiving mode: dual-channel, superheterodyne;

Image suppression:45dBm

Receiving sensitivity: <-99dBm;

Frequency synchronization mode: FM;

Audio output: 1 stereo headphone output

Headphone output power: 80mW@16Q

Power supply: built-in 3.7V lithium battery;

can also support external power bank power supply Normal working current: 130mA

Battery use time: 2-6 hours

TRANSMITTER TECHNICAL PARAMETERS

Carrier bandwidth: 560~590MHz Oscillation mode: PLL frequency synthesis; Transmit power: 10mW; Carrier error: 0.005%; Harmonic radiation: -32dBm; Modulation mode: GFSK Frequency error: <=10ppm Stereo input interface: 3.5mm Input impedance: 2.2KQ; Frequency setting: FM; Power supply: built-in 3.7V lithium battery ;

It can also support external power bank power supply Normal working current: 160mA; Battery use time: 24 hours;
